KIT (AX142100 Protocol Converter, Ethernet / RS-422 / 2 RS-232 / SAE J1939 CAN, AX070533 Cable, AX070531 Cable)
KIT (AX142100 Protocol Converter, Ethernet / RS-422 / 2 RS-232 / SAE J1939 CAN, AX070533 Cable, AX070531 Cable)
Item # AX142100K — KIT (AX142100 Protocol Converter, Ethernet / RS-422 / 2 RS-232 / SAE J1939 CAN, AX070533 Cable, AX070531 Cable)
The Protocol Converter comes pre-programmed with standard protocol conversion logic for bidirectional data exchange between Ethernet (proprietary TCP communications), RS-422 bus, RS-232 bus, RS-485 bus, and CAN network (SAE J1939). Data is forwarded “as-is” between the different serial ports. Also, CAN / Ethernet data is forwarded directly to serial interfaces with the configuration allowing the user to specify the CAN message ID (or TCP port) to listen for data to be forwarded. The module is IP67 rated for rugged vehicle environments.
Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.
Downloads
Datasheet
User Manual
2D Drawing
Step Files (3D)
