24VDC to 24VDC, 95-125W Isolated Converters
The DC-DC Converters provide clean 24VDC power suitable for instrumentation and control networks or process equipment. For operation under the most harsh and demanding conditions, the units are fully sealed, IP67-rated, and enclosed to protect against moisture, shock and vibration. Power from a battery or other source in the range of 9-36VDC is converted to a 24VDC output regulated to 1%. Input and output isolation is provided. The converters are designed with extremely rugged surge and transient suppression in addition to sustained over/under voltage protection. With a nominal nameplate rating of 95W (12VDC input) the DC-DC Converter has an efficiency rated at >91%. With an output rating of 125W (24VDC input) output power, the DC-DC Converter has an efficiency rated at >92%.
| P/N | Part Name | Isolation | Supply Voltage (VDC) | Voltage Output (VDC) | Output Power (W) | Communications | |
|---|---|---|---|---|---|---|---|
| AX080900 | 24VDC to 24VDC, 125W Isolated Converter | Yes | 24 | 24 | 125, 95 | ||
| AX080900K | KIT (AX080900 Converter, WH-DT06-4S-S-16AWG-2M Wire Harness) | Yes | 24 | 24 | 125, 95 |
