0-200mA to 485 Hz PWM Signal Converter, DIN Rail Mount

Item # IPWM-DR-200mA — 0-200mA to 485 Hz PWM Signal Converter, DIN Rail Mount

All Downloads

The 0-200mA to 485 Hz PWM Signal Converter provides a compact DIN rail mount solution for converting a 0-200mA current signal into a digital 485 Hz PWM (Pulse Width Modulation) signal. Input is isolated.

Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.

Add to Quote

QTY

Specifications

Order Code

P/N: IPWM-DR-200mA (0-200mA to 485 Hz PWM)

Input(s)

0-200mA

Output(s)

PWM (485 Hz, 5-90%)
Open Collector

Response Time

<40 ms

Operating Voltage

24VDC Nominal (15...45VDC)

Enclosure

Polycarbonate, DR12
DIN Rail Mount

Connection(s)

#14-24 AWG Screw Terminals

Protection Rating

Encapsulated
IP40 rated enclosure
IP20 rated terminals

Operating Temperature

0 to 95% Relative Humidity
-40 to 85 ºC
-40 to 185 ºF

Applications

Mobile Equipment
Industrial Controls

More +

Downloads

Datasheet

IPWM/PWMI Datasheet

STEP File

JIT-DR-12 Housing

Compliance

RoHS - DoC - All

LVD - DoC - All
