10 Universal Signal Inputs Controller, +5V Reference, SAE J1939
Item # AX030120A — 10 Universal Signal Inputs Controller, +5V Reference, SAE J1939
The AX030120A CAN controller accepts up to ten signal inputs and features a reference voltage of 5 V. The controller accepts voltage, current, frequency, PWM, counter, and digital type inputs and can be connected to a variety of analog machine levers and sensors, PLCs, switches, and PWM signals. The 10 Universal Signal Inputs Controller provides standard embedded software and interfaces with a machine’s SAE J1939 CAN network. The AX030120A setpoints are user configurable via the Axiomatic Electronic Assistant (sold separately). The rugged packaging in addition to the wide-ranging power supply input of 8 to 60 VDC (12, 24, or 48 VDC nominal) ensures that the 10 Universal Signal Inputs Controller, AX030120A, is suitable for applications in the harsh environment of mobile equipment such as power generator sets, construction equipment, and heavy-duty industrial machine controls.
Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.
Technical Specifications
10 Universal Signal Inputs Controller, +5V Reference, SAE J1939
Order Code
P/N: AX030120A
No. of Input(s)
10
Input(s)
10 signal inputs, user selectable as follows:
Voltage (0-1 V, 0-2.5 V, 0-5 V, 0-10 V)
Current (0-20 mA, 4-20 mA)
PWM (up to 10,000 Hz)
Frequency (up to 10,000 Hz)
Counter
Digital (10 kΩ pull-up/pull-down)
Reference Voltage(s)
+5 V, 100 mA ± 2%
No. of Communication Port(s)
1
CAN Port(s)
1 SAE J1939 port
CAN Baud Rate
250 kbit/s, 500 kbit/s, 667 kbit/s, and 1 Mbit/s with auto-baud-rate detection
Operating Voltage
12/24/48 VDC nominal (8-60 VDC)
Control Logic
Standard embedded software is provided.
A user programmable functionality is accessible.
Enclosure
High temperature nylon housing, TE Deutsch P/N: EEC-325X4B
Connection(s)
1x 24-pin connector, TE Deutsch P/N: DTM13-12PA-12PB-R008
Protection Rating
IP67, the unit is conformal coated within the housing
Operating Temperature
-40 to 85 ºC
-40 to 185 ºF
User Interface
The user programmable functionality is accessible using the Axiomatic Electronic Assistant, P/N: AX070502 or P/N: AX070506K
Applications
Construction equipment
Heavy-duty industrial machine control
Power generator sets
Accessories
PL-DTM06-12SA-12SB Mating Plug KIT (DTM06-12SA, DTM06-12SB, 2 WM-12S, 24 Contacts, Plugs)
Datasheet
User Manual
2D Drawing
