4 Thermocouple, 10 Signal Inputs Controller / Data Logging Power Box, SAE J1939, 250 kbps

Item # AX181000 — 4 Thermocouple, 10 Signal Inputs Controller / Data Logging Power Box, SAE J1939, 250 kbps

All Downloads

The 4 Thermocouple, 10 Signal Inputs CAN Controller receives inputs from engine coolant, fuel and differential pressure sensors, engine temperature sensors, thermistors as well as thermocouples and is networked to a CAN (SAE J1939) based control system. Seven (7) +5V references (10 mA) are provided to power the sensors. The 2 CAN bus ports are isolated from signal inputs and thermocouple inputs. It can be installed in control panels, industrial control automation systems, power generator set control systems, off-highway equipment, construction machines, and test equipment.

Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.

Add to Quote

QTY

Specifications

Order Code

P/N: AX181000

Input(s)

4 Thermocouple Inputs (Type J, K, or T)
7 Analog Voltage/Current Inputs (0-5V, 0-10V, 4-20 mA or 0-20 mA)
3 Universal Signal Inputs (0-5V, Thermistor, 0-20 mA, 4-20 mA, PWM, Frequency or Counter, Discrete)

Reference Voltage(s)

+5 V, 10 mA

Communications

2 Isolated CAN ports (SAE J1939)

CAN Baud Rate

250 kbit/s

Operating Voltage

12/24/48 VDC nominal (9-60 VDC)

Enclosure

High temperature nylon housing, TE Deutsch P/N: EEC-5X650B

Connection(s)

Based on availability, the connector will be one of the following:
1x 48-pin connector, TE Deutsch P/N: DT13-48PABCD-R015
1x 48-pin connector, Amphenol Face Plate P/N: ATM13-12PA-12PB-BM03

Protection Rating

IP67

Operating Temperature

-40 to 85 ºC
-40 to 185 ºF

Compliance

CE Marking

Applications

CAN bus Networked Automation
CAN bus Networked Vehicle
Control Systems
Test Equipment

Accessories

AX070123, Mating Plug Kit (DT06-12SA, DT06-12SB, DT06-12SC, DT06-12SD, 4 W12S-P012, 48 Contacts, 15 Plugs)

AX070506K, Axiomatic Electronic Assistant KIT (AX070506 USB-CAN Converter, 3 Cables, Installation Instructions)

More +

Downloads

Datasheet

AX181000 Datasheet

User Manual

AX181000 User Manual

2D Drawing

AX181000 Drawing

STEP File

48-Pin TE Deutsch Housing Assembly

Compliance

EMC - DoC - AX181000

UKCA - DoC - AX181000

RoHS - DoC - All

LVD - DoC - All
