5A Brushed DC Motor Controller, SAE J1939, 250 kbps
Item # AX100600 — 5A Brushed DC Motor Controller, SAE J1939, 250 kbps
The AX100600 provides smooth and precise speed control with CAN communications for bidirectional, brushed and other DC motors. This controller is compact, rugged with an IP67 rating and is designed for highly efficient and reliable power control.
Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.
Order Code
P/N: AX100600 (SAE J1939, 250 kbps)
Input(s)
User selectable,
Choose one input from the following:
0-5 V
0-10 V
4-20 mA
0-20 mA
PWM signal (100 Hz-10 kHz, 0-100%)
A digital input from a switch or other source
Output(s)
H-bridge
5 A @ 24 VDC continuous at room temperature
7.5 A @ 24 VDC for 5 minutes at room temperature
Communications
1 CAN port (SAE J1939)
1 RS-232 port for monitoring and software updates
Operating Voltage
12/24 VDC nominal (9-36 VDC)
Control Logic
Standard embedded software is provided.
The user programmable functionality is accessible using the Axiomatic Electronic Assistant (EA), P/N: AX070502 or P/N: AX070506K
Enclosure
Aluminum housing, integral connector
Encapsulated
Connection(s)
1 3-pin M8 P/N: NAN-T-3MR-M8
1 12-pin connector equivalent to the TE Deutsch P/N: DT15-12PA
Protection Rating
IP67
Operating Temperature
-40 to 85 ºC
-40 to 185 ºF
Applications
Position or closed loop speed control for heavy equipment (Construction, Forestry, etc.)
Accessories
Datasheet
User Manual
2D Drawing
STEP File
Compliance
