8 Inputs, 5 Outputs, Valve Controller, SAE J1939
Item # AX021910 — 8 Inputs, 5 Outputs, Valve Controller, SAE J1939
The AX021910 is in planned obsolescent phase. It is being superseded by a newer model, the AX021210A.
The 8 Input, 5 Output Valve Controller is designed for versatile control of up to five proportional outputs to directly drive coils or other loads. Its flexible circuit design gives the user a wide range of configurable input or output types. The powerful microcontroller and control algorithms allow the user to program the controller for a wide range of applications without the need for custom software. The controller has seven fully programmable universal inputs that can be set up to read voltage, current, resistive, frequency, or digital input signals. For added flexibility, the AX021910 controller also has a magnetic sensor circuit that can read AC signals and convert them into a frequency (RPM) pickup. Five universal outputs are featured and can be set up to drive proportional current (up to 3.5 A each), hotshot digital current, proportional voltage (up to supply), PWM duty cycle, or straight digital on/off loads. The output current must not exceed 8 A at power pin regardless of Vps. The AX021910 valve controller is highly programmable and allows the user to configure it for their application. Its control algorithms allow for open or closed loop drive of the proportional outputs. It can be operated as either a self-contained control system, driving the outputs directly from the onboard inputs, or be integrated into a CAN network of controllers. All I/O and logical function blocks on the unit are inherently independent from one another but can be programmed to interact in several ways. The controller is user-configurable via the Axiomatic Electronic Assistant. The valve controller features a number of built-in protections that can shut off the outputs in adverse conditions. The protection features include hardware shutoffs to protect the circuits from being damaged, as well as software shutdown features that can be enabled in safety critical systems.
If you require 10 outputs, please order the AX021210A — CAN to 10 Output Valve Controller, SAE J1939.
Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.
Downloads
Datasheet
User Manual
2D Drawing
Step Files (3D)
Compliance
