CAN to 2 Analog/Digital and 1 Relay Output Converter, SAE J1939

Item # AX130750 — CAN to 2 Analog/Digital and 1 Relay Output Converter, SAE J1939

All Downloads

The CAN to 2 Analog/Digital and 1 Relay Output Converter, AX130750, features 2 analog/digital signal outputs configurable as voltage, current, frequency, or PWM as well as 1 relay output. Communication is over an isolated SAE J1939 CAN port with a user configurable functionality via the Axiomatic Electronic Assistant (sold separately). The converter is operational at 12 or 24 VDC nominal (9 to 36 VDC) and features auto-baud-rate detection. The AX130750 converter meets the surge requirements of SAE J1445 and is designed for EMC compliance.

Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.

Add to Quote

QTY

Specifications

Technical Specifications

CAN to 2 Analog/Digital and 1 Relay Output Converter, SAE J1939

Order Code

P/N: AX130750

No. of Output(s)

Output(s)

2 analog/digital signal outputs are user selectable as follows:
Voltage (0-5 V, 0-10 V)
Current (0-20 mA, 4-20 mA)
Frequency or PWM (0.1 Hz to 20 kHz, 0-100% duty cycle)

1 Form C relay output

No. of Communication Port(s)

Communications

1 Isolated CAN (SAE J1939)

CAN Baud Rate

Auto-baud rate detection

Operating Voltage

12/24 VDC nominal (9-36 VDC)

Isolation

300 Vrms isolation for the CAN port

Control Logic

Standard embedded software is provided.
A user programmable functionality is accessible.

Enclosure

Molded enclosure, integral connector
Nylon 6/6, 30% glass, ultrasonically welded

No. of Connections

Connection(s)

1x 12-pin connector, equivalent to TE Deutsch P/N: DTM04-12PA

Protection Rating

IP67

Operating Temperature

-40 to 85 ºC
-40 to 185 ºF

User Interface

The user programmable functionality is accessible using the Axiomatic Electronic Assistant (EA), P/N: AX070502 or P/N: AX070506K

Applications

Diesel engines
Throttle controls for marine engines

Accessories

PL-DTM06-12SA, Mating Plug KIT (DTM06-12SA, WM-12S, 12 Contacts, 6 Plugs)

AX070502, Axiomatic Electronic Assistant KIT (AX070501 USB-CAN Converter, 2 Cables, Installation Instructions)

AX070506K, Axiomatic Electronic Assistant KIT III (AX070506 USB-CAN Converter, 3 Cables, Installation Instructions)

No. of Input(s)

More +

Downloads

Datasheet

AX130750 Datasheet

User Manual

AX1307x0 User Manual

2D Drawing

AX130750 Drawing

STEP File

12-Pin Laser Welded Assembly

Compliance

EMC - DoC - AX1307XX

UKCA - DoC - AX1307X0

RoHS - DoC - All

LVD - DoC - All
