RSD-DR-10V-1.2A, 10V, 1.2A Remote Mount Solenoid Driver, DIN Rail Mount

Item # RSDDR10V-0000002 — RSD-DR-10V-1.2A, 10V, 1.2A Remote Mount Solenoid Driver, DIN Rail Mount

All Downloads

The Remote Mount Solenoid Driver simplifies control of proportional solenoids by supplying a current proportional to a 0-10V input signal. It utilizes high frequency switching output (PWM) to provide a DC current output. Current outputs vary by model number. The user can adjust maximum and minimum current, ramp time, dither frequency and amplitude.

Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.

Add to Quote

QTY

Specifications

Order Code

P/N: RSDDR10V-0000002

Input(s)

0-10 VDC voltage signal, or
0-20 mA current signal

Range Of Maximum Output Current

1.2A

Operating Voltage

Accepts up to a maximum of 32 VDC
9...28 VDC

Enclosure

DIN Rail Mount
90.0 x 68.0 x 70.0 mm
3.54 x 2.67 x 2.75 inches
(W x L x H excluding foot)

Connection(s)

10 screw terminals accept 16-20 AWG wire for the power conductors and 18-24 AWG wire for the signal conductors

Protection Rating

Circuit board is conformal coated.

Operating Temperature

-40 to 85 ºC
-40 to 185 ºF

Applications

Accurate control of hydraulic and pneumatic proportional solenoid valves used in mobile equipment and industrial processes.

Input Resistance

Voltage mode: 250K Ohms
Current mode: 33 Ohms

More +

Downloads

Datasheet

TD1501AX Datasheet

Compliance

RoHS - DoC - All

LVD - DoC - All
