0-10V to Bipolar Current (200mA) Converter, DIN Rail Mount

Item # IC-DR-23 — 0-10V to Bipolar Current (200mA) Converter, DIN Rail Mount

All Downloads

This Voltage to Bipolar Current Converters accept 24 VDC power supply (nominal). A 0-10V voltage input signal is converted to a bipolar current (+/-200mA) output. Span and zero is user adjustable. The load can be floating or grounded. Diagnostic LEDs indicate power and operational status. The PCB is conformal coated. The unit is available in a DIN rail mount enclosure.

Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.

Add to Quote

QTY

Specifications

Order Code

P/N: IC-DR-23

Input(s)

0-10 VDC

Output(s)

+/-200 mA

Operating Voltage

24VDC Nominal (16...32VDC power supply range)

Enclosure

Polycarbonate, DR12 housing
35mm DIN rail mount

Connection(s)

Screw Terminals Accept 14-24 AWG Wire

Protection Rating

Conformal coated PCB
IP40 rated housing, IP20 rated terminals

Operating Temperature

-40 to 85 ºC
-40 to 185 ºF

Applications

Mobile Equipment
Industrial Hydraulics

More +

Downloads

Datasheet

IC-DR-YY Datasheet

STEP File

JIT-DR-12 Housing Assembly

Compliance

EMC - DoC - ICDR13 Family

RoHS - DoC - All

LVD - DoC - All
