0-10V to 100 Hz PWM Signal Converter, DIN Rail Mount

Item # AX030004 — 0-10V to 100 Hz PWM Signal Converter, DIN Rail Mount

All Downloads

The 0-10V to 100 Hz PWM Signal Converter provides a compact DIN rail mount solution for converting a 0-10V voltage signal into a digital 100Hz PWM (Pulse Width Modulation) signal. 3-way isolation between power supply, input, and output is provided.

Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.

Add to Quote

QTY

Specifications

Order Code

P/N: AX030004 (0-10V to 100 Hz PWM)

Input(s)

0-10 VDC

Output(s)

PWM (100 Hz, 0-100%)
Open collector

Response Time

<40 ms

Operating Voltage

12Vdc or 24Vdc nominal

Isolation

3-way isolation

Enclosure

Polycarbonate, DR12
DIN Rail Mount

Connection(s)

#14-24 AWG Screw Terminals

Operating Temperature

0 to 95% Relative Humidity
-40 to 85 ºC
-40 to 185 ºF

Applications

Industrial Control Panels
Mobile Equipment

More +

Downloads

Datasheet

AX0300XX Datasheet

2D Drawing

AX030004 Drawing

STEP File

JIT-DR-12 Housing

Compliance

RoHS - DoC - All

LVD - DoC - All

0-10V to 100 Hz PWM Signal Converter, DIN Rail Mount-main
