16 Port Gigabit Ethernet Switch with PoE
Item # AX140730 — 16 Port Gigabit Ethernet Switch with PoE
The AX140730 is an unmanaged switch enabling communication between up to 16 gigabit Ethernet devices. This 16 port gigabit Ethernet switch provides 16 Ethernet ports (10, 100, or 1000 Mbit/s) and 2 power ports. It can power 8 Ethernet devices with Power-over-Ethernet (PoE). It operates with battery voltages of 12, 24, or 48 VDC (nominal). The AX140730 features 18 LED indicators; 1 LED for each port on the device. The unit features 18 M12 connectors and is rated IP67 for rugged applications in harsh environments.
Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.
The AX140730 is an unmanaged switch enabling communication between up to 16 gigabit Ethernet devices. This 16 port gigabit Ethernet switch provides 16 Ethernet ports (10, 100, or 1000 Mbit/s) and 2 power ports. It can power 8 Ethernet devices with Power-over-Ethernet (PoE). It operates with battery voltages of 12, 24, or 48 VDC (nominal). The AX140730 features 18 LED indicators; 1 LED for each port on the device. The unit features 18 M12 connectors and is rated IP67 for rugged applications in harsh environments.
Technical Specifications
16 Port Gigabit Ethernet Switch with PoE
Order Code
P/N: AX140730
LED Outputs
18 LED indicators
Communications
16 gigabit Ethernet ports (10, 100, or 1000 Mbps)
Power-over-Ethernet (PoE) provided
Unmanaged switch enabling communication between 16 different Ethernet devices
Ethernet Port(s)
16 ports (10, 100, or 1000 Mbps)
2 ports provide Power-over-Ethernet (PoE)
Operating Voltage
12/24/48 VDC nominal
Connection(s)
2 M12 connectors (L-coded), Phoenix
16 M12 connectors (X-coded), Phoenix
Protection Rating
IP67
Operating Temperature
-40 to 65 ºC
-40 to 149 ºF
Overview
2D Drawing
