CAN to USB-C Converter, DIN Rail Mount
Item # AX070550 — CAN to USB-C Converter, DIN Rail Mount
The AX070550 converter has one high-speed USB 2.0 Type-C port (up to 480 Mbit/s) and one high-speed CAN port (with configurable baud rates up to 1 Mbit/s). All standard and extended CAN frames, including data and remote frames, are supported. Galvanic isolation of the CAN port ensures no electrical interference between the HMI (or a computer) and equipment connected to the CAN port. The converter is powered from the USB port. The internal state of the converter is displayed by an LED indicator on the housing. The industrial temperature range (-40°C to 85°C) is suitable for a field environment.
Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.
The AX070550 converter has one high-speed USB 2.0 Type-C port (up to 480 Mbit/s) and one high-speed CAN port (with configurable baud rates up to 1 Mbit/s). All standard and extended CAN frames, including data and remote frames, are supported. Galvanic isolation of the CAN port ensures no electrical interference between the HMI (or a computer) and equipment connected to the CAN port. The converter is powered from the USB port. The internal state of the converter is displayed by an LED indicator on the housing. The industrial temperature range (-40°C to 85°C) is suitable for a field environment.
Technical Specifications
CAN to USB-C Converter, DIN Rail Mount
Order Code
P/N: AX070550
Communications
1x CAN port
1x USB-C port
CAN Port(s)
1x CAN port (CAN 2.0A/CAN 2.0B)
CAN Baud Rate
10 kbit/s, 20 kbit/s, 50 kbit/s, 125 kbit/s, 250 kbit/s, 500 kbit/s, 667 kbit/s, 800 kbit/s, 1 Mbit/s or a custom value
Isolation
1x isolated CAN port (400 VAC, 3 kVDC)
Enclosure
DIN Rail enclosure
Connection(s)
1x USB Type-C receptacle
1x CAN connector, Phoenix Contact P/N: MSTBO 2,5/ 4-G1R THRR44 BK
The following mating CAN connector is supplied:
1x 4-pin connector, Phoenix Contact P/N: PSPT 2,5/ 4-ST KMGY
Operating Temperature
-40 to 85 ºC
-40 to 185 ºF
Applications
Communication between an HMI or other user-level software with CAN devices in industrial equipment.
Communication link between a CAN network and a USB port on a Linux machine.
Datasheet
User Manual
2D Drawing
Compliance
