2 Universal Input, Dual Valve Controller, SAE J1939

Item # AX022400 — 2 Universal Input, Dual Valve Controller, SAE J1939

All Downloads

The 2 Universal Inputs, Dual Output Valve Controller is designed for extremely versatile control of up to two proportional outputs to directly drive coils or other loads. Its flexible circuit design gives the user a wide range of configurable input or output types. The sophisticated control algorithms allow the user to program the controller for a wide range of applications without the need for custom software. The controller has two fully programmable universal inputs that can be setup to read: voltage, current, resistive, frequency, or digital input signals. There are also two universal outputs that can be setup to drive: proportional current (up to 3A each); hotshot digital current; proportional voltage (up to supply); proportional PWM; or straight on/off digital loads. All I/O ports on the unit are independent from one another.

The controller is a highly programmable controller, allowing the user to configure it for their application. Its sophisticated control algorithms allow for open or closed loop drive of the proportional outputs. It can be operated as either a self-contained control system, driving the outputs directly from the on-board inputs, and/or it can be integrated into a CAN J1939 network of controllers. All I/O and logical function blocks on the unit are inherently independent from one another, but can be programmed to interact in a large number of ways.

The device has a number of built-in protection features that can shut off the outputs in adverse conditions. They include hardware shutoffs to protect the circuits from being damaged as well as software shutdown features that can be enabled in safety critical systems. All setpoints are user configurable using the Electronic Assistant.

Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.

Add to Quote

QTY

Specifications

Order Code

P/N: AX022400

Input(s)

2 universal signal inputs configurable as:
Voltage
Current
Resistive
PWM
Frequency/RPM
Digital

Output(s)

2 independent software controlled outputs selectable as:
Proportional Current
Hotshot Digital
PWM Duty Cycle
Proportional Voltage
On/Off Digital Types

Communications

SAE J1939

Operating Voltage

12, 24, 48VDC nominal (9…60 VDC power supply range)

Control Logic

User programmable functionality using the Electronic Assistant (EA),
P/N: AX070502 or P/N: AX070506K

Enclosure

Aluminum enclosure, integral TE Deutsch Equivalent connector
Encapsulated (DOW Sylgard Silicone Elastomer 170)

Protection Rating

IP67 rating for the product assembly.

Operating Temperature

-40 to 85 ºC
-40 to 185 ºF

Accessories

AX070105, Mating Plug KIT (DT06-12SA, W12S, 12 Contacts, 6 Plugs)

AX070502, Axiomatic Electronic Assistant KIT (AX070501 USB-CAN Converter, 2 Cables, Installation Instructions)

AX070506K, Axiomatic Electronic Assistant KIT III (AX070506 USB-CAN Converter, 3 Cables, Installation Instructions)

More +

Downloads

Datasheet

AX022400 Datasheet

User Manual

AX0224X0 User Manual

STEP File

AX022400 Housing Assembly

Compliance

RoHS - DoC - All

LVD - DoC - All
