Automotive Ethernet to CAN Protocol Converter

Item # AX141530 — Automotive Ethernet to CAN Protocol Converter

All Downloads

The Axiomatic Automotive Ethernet to CAN Converter provides a purely physical, bi-directional conversion between Automotive Ethernet (100BASE-T1) and CAN 2.0B via PHY transceivers. No packets are stored or modified in this device. The Automotive Ethernet fieldbus supports bit rates of 100 Mbps, and the CAN bus supports baud rates up to 1 Mbps. Status LEDs provide information on the connection link and communication. The converter is designed for the harsh environments of off-highway or industrial equipment. A 700 mA output is available to power another device downstream on the system.

The converter is configured as Master or Slave functionality via an internal web server interface using an Automotive Ethernet/Ethernet Converter (AX141550) or a similar device to access Ethernet, which links to the web server. Its default setting is in the Slave mode. The Master mode works if the connected device has a transceiver set to Slave mode. The Slave mode works when the connected device has a transceiver set to Master mode. Hard setting the Master/Slave relationship saves on setup-time costs and ensures that the Automotive Ethernet link is established quickly. As a comparison, regular Ethernet converters rely on auto-negotiation to determine master and slave.

To purchase the AX141530 Automotive Ethernet to CAN Protocol Converter as a kit with mating cables, please visit: AX141530K — KIT (AX141530 Converter, AX070532 Cable, AX070534 Cable)

Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.

Add to Quote

QTY

Specifications

Technical Specifications

Automotive Ethernet to CAN Protocol Converter

Order Code

P/N: AX141530

Output Current

700 mA

CAN Port(s)

1 SAE J1939 port

CAN Baud Rate

10 kbit/s, 20 kbit/s, 50 kbit/s, 83 kbit/s, 100 kbit/s, 125 kbit/s, 250 kbit/s, 500 kbit/s, 667 kbit/s, or 1 Mbit/s with auto-baud-rate detection

Automotive Ethernet Port(s)

1 Automotive Ethernet port (100 Mbit/s)
100BASE-T1 compliant (IEEE 802.3bw)
Automatic polarity correction
Default configuration: Slave

Operating Voltage

12/24 VDC nominal (9-36 VDC)

Functionality

Can be configured as Master or Slave

Control Logic

A user programmable functionality is accessible.

Enclosure

Ultrasonically welded
Nylon 6/6, 30% glass fill

Connection(s)

1x 4-pin M12 connector (D-coded), Phoenix Contact P/N: 1441752
1x 5-pin M12 connector (A-coded), Phoenix Contact P/N: 1441778

Operating Temperature

-40 to 80 °C
-40 to 176 °F

User Interface

The user configurable functionality is accessible via an internal web server interface using an Automotive Ethernet/Ethernet Converter or a similar device to access Ethernet, which links to the web server.

Applications

Industrial trucks
Mining equipment
Off-highway equipment

Accessories

AX070532, CAN Cable, 2.0 m (6.5 ft), 5-Pin M12 A-Coded Connector, Unterminated Leads

AX070534, Power and AE Cable - 2 m (6.56 ft.), 4-pin Male M12 D-coded, Unterminated Leads

Configuration Accessories:
AX141550, Gigabit Automotive Ethernet / Gigabit Ethernet Converter, A-Coded Connectors

AX070535, 2m (6.5 ft.), 8-pin M12 A-coded, Ethernet Jack, Ethernet Cable

More +

Downloads

Datasheet

AX141530 Datasheet

User Manual

AX141530 User Manual

2D Drawing

AX141530 Drawing

Compliance

EMC - DOC - AX1415XX

UKCA - DoC - AX1415XX

RoHS - DoC - All

LVD - DoC - All

Automotive Ethernet to CAN Protocol Converter-main
