KIT(AX081850 Converter, AX070158 Wire Harness, AX070154 Wire Harness)

Item # AX081850K — KIT(AX081850 Converter, AX070158 Wire Harness, AX070154 Wire Harness)

All Downloads

This 24VDC/24VDC Non-isolated converter operates from 9-36VDC with output current derating for input voltage less than 12VDC. It offers a typical efficiency of 95%, with input inrush current limit to avoid gradual damage to components. This unit also uses thermal protection for over temperature, over and under-voltage protection, and short circuit and overcurrent protection. This product is suitable for engine cranking and load dump.

Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.

Add to Quote

QTY

Specifications

Order Code

KIT P/N: AX081850K (Includes Wire Harnesses)

Input(s)

24 VDC Nominal (9-36 VDC)

Output(s)

24 VDC +/- 2% (720 W)

Output Current

30 A Continuous

Isolation

Not provided

Enclosure

Cast Aluminum housing, integral gasket and connector
8.14 x 11.12 x 3.11 inches
L x W x H including integral connectors

Connection(s)

1 12-pin connector equivalent to the TE Deutsch P/N: DT13-12P
1 6-pin connector equivalent to the TE Deutsch P/N: DT13-6P

Protection Rating

IP67

Compliance

For compliance of the device, please see the compliance downloads on the device page.

Applications

Off-highway Equipment
Oilfield equipment
Power generator set control systems
Telecom

More +
