KIT (AX140900RST CAN/Ethernet Converter, AX070531 Ethernet and Power Cable and AX070532 CAN Cable)
Item # AX140900RSTK — KIT (AX140900RST CAN/Ethernet Converter, AX070531 Ethernet and Power Cable and AX070532 CAN Cable)
The Ethernet/CAN Converter handles communication between Ethernet IEEE 802.3, IP ICMP, ARP, UDP, TCP, HTTP or proprietary protocol devices and CAN bus. Communication can occur in either direction.
Our products are designed to be customized by our customers and can be thought of as product foundations. Find the foundational product(s) that you need in our catalog, add them to your quote cart, then explain your requirements for your project on the quote cart submission form. If you cannot find the foundational product, please tell us your requirements.
Order Code
P/N: AX140900RSTK
CAN Port(s)
1 Port: High speed, ISO 11898-2 compatible, 1 Mbit/s Shield is provided.
Ethernet Port(s)
1 Port: 10/100 Mbit Ethernet Compliant
10BASE-T, 100BASE-Tx (Auto-configuration and Full-duplex Supported)
Operating Voltage
12VDC or 24VDC Nominal (9...36VDC Power Supply Range)
Enclosure
Nylon 6/6, 30% glass fill
UL 94V-0
Ultrasonically welded
4.188 x 1.813 x 1.319 inches
106.37 x 46.04 x 33.51 (L X W X H)
Connection(s)
1 Phoenix Contact M12 8-pin connector (A-coded), P/N: 1441817 (Connector 1).
Protection Rating
IP66 (IEC 60529)
Operating Temperature
-40 to 70 ºC
-40 to 158 ºF
Compliance
For compliance of the device, please see the compliance downloads on the device page.
Applications
Off-highway Equipment
Mining Equipment
Industrial Control Panels
Datasheet
User Manual
2D Drawing
STEP File
